Inline Gear Motor

Get a Price/Quote

Product Details:

Bearing Type Ball Bearing
Efficacy IE2 / IE3
Standard IS:325, IEC
Starting Type Direct On Line (DOL)
Rated Frequency 50 Hz
Pressure Standard
Poles Number 2/4/6 Poles
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Inline Gear Motor Product Specifications

Ambient Temperature -20C to +50C
Current Type AC
Voltage 415 V AC
Power Rating 0.18 kW to 15 kW
Rated Voltage 415 V
Speed 1440-2800 RPM
Sealed Type Sealed
Dimension (L*W*H) As per model
Frequency (MHz) 50-60 Hz
Torque Up to 1800 Nm
Cooling Method TEFC (Totally Enclosed Fan Cooled)
Product Type Inline Gear Motor
Phase Three Phase
Motor Type Inline Gear Motor
Mounting Type Foot / Flange Mounted
Features Compact design, High efficiency, Long service life, Low maintenance
Weight 10 kg to 95 kg
IP Rating IP55
Horse Power 0.25 HP to 20 HP
Efficacy IE2 / IE3
Color Blue or Grey
Bearing Type Ball Bearing
Shaft Diameter 19 mm to 55 mm
Starting Type Direct On Line (DOL)
Output Power 0.25 HP to 20 HP
Standard IS:325, IEC
Rated Frequency 50 Hz
Pressure Standard
Power 0.18 kW to 15 kW
Poles Number 2/4/6 Poles
Protect Feature Totally Enclosed Fan Cooled (TEFC)
Noise Level <75 dB

Overload Capacity Up to 150%
Duty S1 (Continuous duty)
Material Cast Iron / Aluminium Body
Thermal Protection Available on request
Gear Ratio 5:1 to 60:1
Application Conveyor, Industrial Machinery, Packaging, Textile, Food Processing
Lubrication Synthetic Gear Oil
Insulation Class Class F

Product Description

Specification

Minimum Order Quantity	1 Piece
Brand	J D Automation
Phase	Single Phase, 3 Phase
Usage/Application	Industrial
Speed	Max 1500 RPM
Power	Up to 0.25Hp
Voltage	230-415V AC
Protection Class	F
Frequency	50/60 Hz

Superior Efficiency and Reliable Performance

This inline gear motor series boasts high energy efficiency (IE2 / IE3), totally enclosed fan cooled (TEFC) protection, and operates at speeds between 1440 and 2800 RPM. With overload capacities up to 150% and optional thermal protection, the motors ensure reliable operation even in the most challenging industrial conditions. Their robust design makes them ideal for continuous duty, enhancing productivity and reducing downtime in various industries.

Designed for Versatility and Longevity

Constructed from strong cast iron or aluminium, these gear motors are available in both foot and flange-mounted configurations. Their sealed, IP55-rated housing protects internal components, ensuring long service life with minimal maintenance. Suitable for use in environments from -20C to +50C, the motors maintain optimal performance and are compatible with standard industrial supply voltages and installation protocols.

FAQ's of Inline Gear Motor:

Q: How is the inline gear motor installed and where can it be used?

A: The gear motor can be installed using either foot or flange mounting, depending on your system requirements. It is widely used in industrial applications such as conveyors, packaging machinery, textile production, and food processing due to its robust construction and adaptable configurations.

Q: What benefits does synthetic gear oil lubrication offer for the gear motor?

A: Synthetic gear oil enhances the lifespan of internal gears and reduces maintenance needs by providing superior lubrication, reducing wear and tear, and ensuring smooth, efficient operation even under high load conditions or continuous duty cycles.

Q: When should thermal protection be considered for this gear motor?

A: Thermal protection is recommended in environments where temperature fluctuations or overload conditions are likely. Although available on request, it is particularly beneficial for continuous-duty processes where overheating risks could impact motor longevity or safety.

Q: What makes the gear motor suitable for continuous (S1) duty?

A: The motor is engineered with Class F insulation, high-quality ball bearings, and efficient cooling (TEFC), allowing it to operate continuously without performance loss. This makes it especially reliable for applications requiring ongoing, uninterrupted operation.

Q: How does the IP55 rating benefit the gear motor in industrial environments?

A: The IP55 rating ensures the motor is protected against dust ingress and water jets, making it suitable for harsh industrial settings. This level of sealing helps extend motor life and maintain performance, even in challenging conditions.

Q: What efficiency standards does the gear motor meet?

A: These motors comply with IE2 and IE3 international efficiency classes, ensuring reduced energy consumption, lower operating costs, and minimal heat generation. They also meet IS:325 and IEC standard requirements for industrial electric motors.
