Three Phase Industrial Gear Motor

Get a Price/Quote

Product Details:

Rated Voltage 415 V
Sealed Type IP55
Efficacy High Efficiency
Current Type AC
Horse Power 1 HP
Voltage 415 V
Power Rating 0.75 kW
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Three Phase Industrial Gear Motor Product Specifications

IP Rating IP55
Output Power 0.75 kW
Poles Number 4
Dimension (L*W*H) 350 x 180 x 250 mm
Pressure Atmospheric
Ambient Temperature -10 to 50C
Standard IEC
Mounting Type Foot Mounted
Efficacy High Efficiency
Sealed Type IP55
Rated Voltage 415 V
Current Type AC
Shaft Diameter 28 mm
Power Rating 0.75 kW
Horse Power 1 HP
Voltage 415 V
Cooling Method Fan Cooled
Motor Type Induction Gear Motor
Bearing Type Ball Bearing
Phase Three Phase
Features Robust Construction, Low Maintenance, High Torque Output
Rated Frequency 50 Hz
Product Type Gear Motor
Noise Level <70 dB
Weight 32 kg
Color Grey
Power 0.75 kW
Frequency (MHz) 50 Hz
Speed 1440 rpm
Torque 5 Nm
Protect Feature Totally Enclosed
Starting Type Direct On Line

Product Description

Specification

Minimum Order Quantity	1 Piece
Usage/Application	Industrial
Brand	J D Automation
Power	0.5 to 500 HP
Phase	Single Phase, 3 Phase
Speed	1500 RPM
Voltage	230-415V AC
Number of Poles	4
Mounting	Foot cum Flange
Frequency	50/60 Hz

High-Performance for Industrial Applications

This gear motor is specially designed for industrial equipment, conveyors, and packaging machinery, providing consistent high torque output (5 Nm) with minimal noise (<70 dB) and vibration (2.0 mm/s). Its helical gears ensure energy-efficient power transmission and smooth operation, catering to heavy-duty continuous processes.

Durability and Reliable Operation

With its cast iron housing, EN8 steel shaft, and IP55 protection, this gear motor thrives in harsh settings. The Class F insulation and grease-lubricated ball bearings extend service life, while built-in thermal protection safeguards against overheating, allowing for safe, low-maintenance operation in ambient temperatures from -10C to 50C.

Ease of Installation and Flexibility

The foot-mounted, flexible coupling design of this motor simplifies installation and integration into existing systems. With support for direct-on-line starting and horizontal mounting, it fits varied industrial setups, making it suitable for manufacturers, exporters, retailers, and wholesalers across India.

FAQ's of Three Phase Industrial Gear Motor:

Q: How is this three phase industrial gear motor installed in equipment?

A: The motor uses a foot-mounted design with flexible coupling, allowing secure and straightforward installation in a horizontal position onto industrial machinery such as conveyors and packaging systems.

Q: What are the main benefits of the grease-lubricated, helical gear system in this motor?

A: The grease lubrication ensures long-lasting, low-maintenance performance, while the helical gears reduce noise and vibrations, enhance energy efficiency, and deliver smooth torque output even under continuous operation.

Q: Where can this gear motor be used effectively?

A: This gear motor is ideal for industrial applications such as conveyors, packaging machinery, and other manufacturing equipment where high durability, reliable torque, and efficient power transmission are essential.

Q: When should thermal protection in the motor be used or checked?

A: Thermal protection is built-in and automatically activates if the motor overheats, safeguarding the equipment. Regular inspection during maintenance routines is recommended to ensure proper function.

Q: What process does the IP55 rating protect the gear motor from?

A: The IP55 rating certifies protection against dust ingress and water jets, ensuring reliable performance and reducing the risk of contamination or electrical faults in demanding industrial environments.

Q: How does the robust construction benefit long-term operation?

A: The cast iron housing, EN8 steel shaft, and ball bearings collectively provide resistance to wear and environmental stress, resulting in dependable, long-lasting performance with minimal repair needs.
