90W Brake Motor

Get a Price/Quote

Product Details:

Cooling Method Self-Cooled (Fan Cooled)
Efficacy IE2 (High Efficiency)
Horse Power 0.12 HP
Current Type AC
Noise Level <58 dB
Power Rating 90 Watt
Pressure Atmospheric
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

90W Brake Motor Product Specifications

Weight Approx. 6.5 Kg
Pressure Atmospheric
Protect Feature Totally Enclosed
IP Rating ip44
Output Power 90W
Power Rating 90 Watt
Power 90W
Noise Level <58 dB
Current Type AC
Frequency (MHz) 50/60
Efficacy IE2 (High Efficiency)
Horse Power 0.12 HP
Mounting Type Foot Mounted
Cooling Method Self-Cooled (Fan Cooled)
Poles Number 4 Poles
Voltage 220V / 380V
Rated Frequency 50 Hz / 60 Hz
Speed 1350 RPM
Product Type Electric Brake Motor
Sealed Type Enclosed
Features High Starting Torque, Low Noise, Thermal Overload Protection, Durable Construction
Bearing Type Ball Bearing
Phase Single / Three Phase
Shaft Diameter 14 mm
Dimension (L*W*H) 285 x 130 x 148 mm
Color Grey
Torque 0.65 Nm
Motor Type AC Brake Motor
Starting Type Direct On-Line (DOL)
Ambient Temperature -15C ~ +40C
Rated Voltage 220V (Single) / 380V (Three Phase)

Duty Cycle S1 (Continuous) Duty
Starting Current 2.2 A
Application Lifting, Conveyor, Machine Tools, Textile Machinery, Packaging
Suitable For Industrial Automation & Packaging
Body Material Cast Iron
Mounting Dimension 100 mm (Foot to Foot)
Insulation Class Class B
Brake Voltage 220V AC
Brake Type AC Fail Safe Electromagnetic Brake
Service Factor 1.0

Product Description

The 90W Brake Motor, revered as a top-rated laureate in its class, is an immaculate choice for industrial automation and packaging needs. Featuring a crackerjack cast iron body, this AC fail-safe electromagnetic brake motor delivers reliable performance with a robust 0.65 Nm torque and IE2 high efficiency. Its totally enclosed and foot-mounted design ensures seamless integration into lifting, conveyor, textile, and machine tool applications. Add to Cart now for proven durability, low noise, and thermal overload protection, making it a top selection for exporters and retailers across India.

Built for EnduranceIdeal for Versatile Industrial Applications

Engineered from cast iron, the 90W Brake Motor offers robustness across diverse work surfaces. Suitable for lifting, conveyor systems, textile machinery, and packaging, this immaculate motor is purpose-designed for general and specific industrial automation tasks. The totally enclosed body, foot-mount option, and self-cooled feature guarantee safe operation in demanding conditions, while its atmospheric pressure resistance and IP44 rating ensure protection and reliability for any application environment.

Sample Availability, Export Markets, and Certifications Simplified

Samples of the 90W Brake Motor are available upon request for testing and evaluation. Rated highly among global buyers, our brake motors are securely shipped and dispatched across main export markets, including Europe, Asia, and the Middle East. Each product is supplied with necessary certifications for quality assurance, making it an excellent option for retailers, wholesalers, and manufacturers alike seeking confidence in both performance and compliance standards.

FAQs of 90W Brake Motor:

Q: How does the electromagnetic brake system function in the 90W Brake Motor?

A: The AC fail-safe electromagnetic brake engages automatically during power loss, ensuring quick and secure stopping for enhanced safety in various automation processes.

Q: What are the specific uses and applications of this brake motor?

A: This motor is ideal for lifting, conveyors, machine tools, textile, and packaging machinery, making it perfect for general and specialized applications across multiple industries.

Q: When is it recommended to use the S1 (Continuous) duty cycle of the motor?

A: The S1 (Continuous) duty cycle is recommended for operations requiring prolonged or uninterrupted performance, maintaining high efficiency and reliability for continuous industrial tasks.

Q: Where can I request a sample or purchase the 90W Brake Motor?

A: Samples and purchases can be requested directly through our exporting, manufacturing, and retail channels across India, ensuring rapid response to inquiries.

Q: What are the main benefits of the cast iron body and thermal overload protection?

A: The cast iron body offers exceptional durability and longevity, while thermal overload protection helps safeguard the motor against overheating, extending its operational life.

Q: How is secure shipping and dispatch handled for export markets?

A: Motors are safely packaged and dispatched with secure shipping methods to ensure they reach main export markets in pristine condition, complying with all relevant certifications.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Brake Motor' category

180W Electromagnetic Brake Motor Weight : 7 kg Output Power : 180W Protect Feature : Totally Enclosed Efficacy : High Efficiency Frequency (MHz) : 50/60 Power : 180W Voltage : 220V / 380V Product Type : Brake Motor Sealed Type : Other, IP44 Speed : 1350 RPM Rated Frequency : 50Hz / 60Hz Dimension (L*W*H) : 220mm x 120mm x 140mm Phase : Other, Single Phase / Three Phase Starting Type : Direct on Line Rated Voltage : 220V/380V IP Rating : ip44 Power Rating : 180 Watts Pressure : Other, Normal Atmospheric Cooling Method : Fan Cooled Horse Power : 0.24 HP Mounting Type : Foot Mounted Noise Level : 55 dB Current Type : AC Poles Number : 4 Bearing Type : Ball Bearing Features : Electromagnetic brake for fast stop, heavy duty construction Color : Grey Shaft Diameter : 14 mm Ambient Temperature : 15C to +40C Motor Type : Electromagnetic Brake Motor Torque : 1.27 Nm Standard : IEC

Send Inquiry

Geared Brake Motor Weight : Varies as per design Output Power : 1 HP to 10 HP (customized range) Protect Feature : Other, Totally Enclosed Fan Cooled (TEFC) Efficacy : High Efficiency Frequency (MHz) : 50 Hz Power : 0.75 kW to 7.5 kW Voltage : 415 V / 230 V Product Type : Other, Geared Brake Motor Sealed Type : Other, IP55 Speed : 1440 RPM / 960 RPM Rated Frequency : 50 Hz Dimension (L*W*H) : Depends on model (customized) Phase : Other, Three Phase / Single Phase Starting Type : Direct On Line (DOL) Rated Voltage : 415 V IP Rating : Other, IP55 Power Rating : 0.75 kW ~ 7.5 kW Pressure : Other, Standard Atmospheric Cooling Method : Fan Cooled Horse Power : 1 HP to 10 HP Mounting Type : Foot Mounted / Flange Mounted Noise Level : Low Noise Operation Current Type : AC Poles Number : Other, 4 Pole (standard), customized available Bearing Type : Deep Groove Ball Bearing Features : Integrated Gearbox with Brake, Robust Construction, Low Maintenance Color : Blue / Grey Shaft Diameter : Custom (standard sizes: 24mm to 38mm) Ambient Temperature : 10C to +50C Motor Type : Squirrel Cage Induction Geared Motor with Brake Torque : Up to 150 Nm (modelspecific) Standard : IS/IEC 600341 certified
