Helical Gear Box SRC 04 - 35 MM Shaft Diameter

Get a Price/Quote

Product Details:

Poles Number 4 Poles
Starting Type DOL
Torque Up to 350 Nm
Pressure Standard Atmospheric
Cooling Method Surface Cooled
Power Rating Up to 7.5 kW
Efficacy High
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Helical Gear Box SRC 04 - 35 MM Shaft Diameter Product Specifications

IP Rating IP55
Power Rating Up to 7.5 kW
Efficacy High
Current Type AC
Bearing Type Heavy Duty Ball Bearing
Ambient Temperature -10C to +50C
Sealed Type Oil Sealed
Mounting Type Foot Mounted
Starting Type DOL
Torque Up to 350 Nm
Poles Number 4 Poles
Output Power Up to 7.5 kW
Shaft Diameter 35 mm
Weight 25 kg (Approx.)
Phase Three Phase
Pressure Standard Atmospheric
Cooling Method Surface Cooled
Product Type Helical Gear Box
Color Blue/Grey
Protect Feature Totally Enclosed
Horse Power 10 HP Max
Voltage 415 V
Noise Level Low
Speed 1440 RPM
Features Rugged Design, High Torque, Low Noise, Compact Structure
Rated Voltage 415 V
Dimension (L*W*H) 310 x 180 x 190 mm (Approx.)
Frequency (MHz) 50 Hz
Motor Type Helical Gear Motor
Power 7.5 kW Max
Rated Frequency 50 Hz

Application Conveyors, Mixers, Packaging Machinery, Industrial Automation
Service Factor 1.0-1.8
Input Method Motor Mounting/Direct Coupling
Gear Ratio 5:1 to 70:1
Heat Dissipation Fins Provided on Housing
Life Expectancy Designed for Long Life Operation
Lubrication Oil Bath/Splash Lubrication
Gear Type Helical
Output Type Solid Shaft
Casing Material High-Grade Cast Iron

Product Description

Discover a monumental opportunity with our renowned Helical Gear Box SRC 04 now available at a rare discount for a limited time. Featuring a masterful combination of high-grade cast iron casing and helical gear technology, this unit boasts exceptional durability, high torque, and low noise operations. Perfect for industrial automation and heavy-duty applications, it offers gear ratios from 5:1 to 70:1, supports up to 7.5 kW power, and includes advanced features like oil bath lubrication and fins for superior heat dissipation. Dont miss this last chance to secure a premium gear solution at unmatched value.

Masterful Engineering for Industrial Excellence

Helical Gear Box SRC 04 35 MM Shaft Diameter stands out for its rugged design, high torque output, and compact structure. Equipped for use in conveyors, mixers, packaging machinery, and a wide array of industrial automation tasks, it delivers reliable results. Key features such as low noise, heavy-duty ball bearings, and versatile mounting options make it ideal for continuous, demanding environments where longevity and precision matter.

Seamless Logistics & Unmatched Value for Businesses

Our Helical Gear Box SRC 04 is available through major Indian transport services at the lowest price, ensuring efficient nationwide delivery. FOB Port options are flexible to suit buyer requirements, with primary distribution across all main domestic markets. We offer sample policies upon request at a competitive asking price, allowing customers to verify quality before purchase and experience the advantages of this renowned product first-hand.

FAQs of Helical Gear Box SRC 04 - 35 MM Shaft Diameter:

Q: How does the SRC 04 Helical Gear Box ensure long operational life?

A: The SRC 04 is crafted with a high-grade cast iron casing, oil bath/splash lubrication, and fins on the housing for effective heat dissipation, ensuring durability and dependable long-term performance.

Q: What applications suit the Helical Gear Box SRC 04 best?

A: This gear box is ideal for conveyors, mixers, industrial packaging machinery, and a variety of industrial automation systems requiring robust power transmission with high torque and low noise.

Q: When should I choose the SRC 04 Helical Gear Box over other gearbox types?

A: Choose the SRC 04 for applications demanding reliable, quiet operation, high efficacy, and long service life, especially where rugged construction and solid shaft output are essential.

Q: Where can I obtain the Helical Gear Box SRC 04 in India?

A: The Helical Gear Box SRC 04 is distributed nationwide across India by exporters, manufacturers, suppliers, retailers, and wholesalers through major transport services and leading industrial marketplaces.

Q: What benefits do the oil-bath lubrication and IP55 rating provide?

A: Oil bath lubrication reduces wear and enhances efficiency, while the IP55 rating ensures protection against dust and water, making the unit reliable in challenging industrial environments.

Q: What is the process for requesting a product sample?

A: Buyers can request a product sample under our sample policy at a competitive asking price. Samples are shipped promptly using trusted transport services, allowing verification of quality before bulk purchase.
